39-meter Steel Schooner for Sale in Turkey
Length Overall : 131 ft / 40. Meters
Length Waterline : 94 ft / 28.80m
Breadth : 31ft / 09.55m
Draught maximum : 13 ft / 03.90m
Displacement : 300 T
Type : Steel Schooner
Building Yard : Bodrum, TURKEY
Year Built : 2005
Hull Material : Steel
Superstructure : Steel veneered with Mahogany
Decks : Teak
Interiors : All accommodation spaces subdivided by fireproof, Panels veneered with cherry wood
Engines : 2 x MAN 675 HP / 2100 RPM
Gearbox : ZF W350
Bowthruster : SP 550 HYD
Speed Max : 12 knots
Speed Cruise : 11 knots
Range : 1000 Nautical miles.
Generator : KOHLER 2 x 55 kW & 1 port generator 23 kW
Air-conditioning : OCEAN BREEZE Tliroughout, self-contained heat / cool Units, independently controlled in each cabin, salon, galley and wheelhouse
Fuel Tanks : 10.000 It.
Fresh Water Tanks : 14.000 It
Waste Tanks : 11.000 It.
Masts : 2 aluminium
Sails : Dacron sails, 5 pieces totally 600 m2, 2 lazy bags
Passenger Accommodation
6 guest cabins for totally 12 passengers
One 48 m2 master suite with walk-in dressing room & 2 bathrooms,
3x VIP guest suites each with bathrooms
One 15m2 double guest cabin with bathroom
One 15m2 triple guest cabin with en-suite bathroom
Crew Accommodation 1 captain (double) with en-suite bathroom & 3 crew cabins accommodating 6 crew & 2 bathrooms.
Galley : Fully equipped galley with ,built in SIEMENS deep-freezer, 2 refrigerators, electric oven & cooker, dishwasher. KALE ice maker.
Main Deck :
80 m2 bar & dining salon
Fully equipped galley & provision rooms, utility room,
day head, wheelhouse forward with crew mess,
85 m2 aft deck area with dining table for guests, steering console, aft cushions
50 m2 of water toys & sports deck forward
110 m2 upper deck with sun bathing cushions
Navigational Equipment :
SIMRAD VHP Radio,
GYRO compass,
SIMRAD echo sounder & speed log
2 x SIMRAD radars
2 x SIMRAD GPS Chartplotters
SEATEL satcom,
SIMRAD autopilot S30
Repeater system for helm positions.
Safety Equipment :
Two life rafts for 14 pax each
Four horse shoe buoys & 26 life-jackets
Smoke detectors in all accommodation spaces, galley &
Engine room, fire extinguishing devices for for
Accommodation spaces.
Automatic controlled C02 system for engine room
Mooring & Deck :
Two DATA vertical hydraulic windlasses with single drums
Two DATA warping capstans on aft deck
HALL type anchores, 2 x 290 kg
22 m calibrated galvanized chains 2 x 140 m
BESENZONI Deck crane, 600 kg / 4,20 m
Stainless steel swimming ladder with teak steps.
Gangway
Entertainment :
SONY Plasma TV, DVD & home theatre system in salon.
LCD TV in master & 2 VIP cabins
NETPA 20′ LCD tv at crew mess in galley
Tenders & Water toys :
1x 5.20 Rib Boat 100 hp Yamaha
1x Boat 5.80 m – 150 hp Yamaha
Main Engine : M.a.n D2842 Le 497kw 2100rpm
Red. Gear : Zf Marine Type: zfw350
Main D/g : Kohler 55efoz 55kw 68.8kva 50hz 1500rpm 104 A
Port D/g : Kohler 23efoz 23kw 28.8kva 50hz 1500rpm 43.7 A
Water Maker : Tecnicomar Model:c1500 230v 50hz 12a Cap:180 Lt/h
Sewage Treatment : Tecnicomar Model:ecomar24 Cap:7000lt/day 1kw 230v
Steering Gear : Data Hidrolik Type:des1se4s 4kw 21lt
Bow Thruster : Side Power Sp550hyd
Fire Pump : Gianneschi Type:acm 502 Bt/3 9,2kw 1450rpm
Emerg. Fire Pump : Gianneschi Type:m-acm 502 B Diesel V 13.5 Kw 1750 Rpm
Grey Water Disc. Pump : 380 V 550lt/min Head 5m
Boiler : Gianneschi Type:150ve 230/400v 6kw Cap:150lt Pmax:5 Bar
Battery : Cell Type:12pozs Din 40736t1 1500ah 2 Set 2x 24v
Battery Charger : Victron Energy 4x100amp
Hidrafor Pump220v : Gianneschi Type:jet 518 B Me 230v 7.4 A 1.1 Kw 2900rpm
Hidrafor Pump24v : Gianneschi Type:jet 518 B 24v 50a 1.1 Kw 2800rpm
Hidrafor Tank : 100 Lt
Bilge Pump : Gianneschi Type:acm 501 Bt /k3 4kw 1450rpm 230/400v 15.2/8.8a
Co2 System : Kalafatoğlu 135kg Co2 (Volume Of The Machine:144 M3)
F.w Tank : 14400 Lt
F.o Tank : 10400 Lt
Grey Water Tank : 7400 Lt
Black Water Tank : 3700 Lt
Bilge Tank : 1000 Lt
Radar : Jrc 48 Miles , Simrad 48 Miles
Music System : Sonos
Tv Satellite : Simrad 90cm
